Aerauliqa WHS

Narrow Air Cone HVLS Fan

High Volume Low-Speed fan designed to move air with a direct narrow air cone. Designed to be installed in high ceilings to redistribute air towards floor level, creates a cooling effect in summer while de-stratifying the air in winter.

Near silent operation thanks to the brushless EC motor and dynamic airfoil design.

Promotes natural cooling in summer and de-stratifies warm air in winter.

Fully speed controllable.

Maintenance free.

Need some help?

Email or call the team on 01384 275771

Overview

The WHS Range of High Volume Low Speed (HVLS) Fans are designed for commercial, industrial and agricultural applications, delivering a narrow, direct distribution cone. They excel at redistributing air towards the floor level, creating a cooling effect in summer and efficiently de-stratifying the air during winter.

The WHS range of compact HVLS fans is engineered to provide efficient air circulation in spaces with high ceilings. By gently moving large volumes of air at low speeds, these fans offer superior comfort and improved indoor air quality. During the summer months, WHS HVLS fans create a refreshing cooling effect, maintaining a pleasant environment for occupants. In contrast, during the colder winter months, they effectively de-stratify the air by pushing the warm air down from the ceiling to the floor level, ensuring an even distribution of heat throughout the space.

One of the significant advantages of WHS HVLS fans is their energy-saving potential. By de-stratifying the air and ensuring a more balanced temperature, these fans reduce the workload on heating and cooling systems, leading to energy efficiency and cost savings.

Features and Benefits

Direct airflow and up to 429464 m3/h
Air distribution under the fan is produced in a narrow cone.
Near silent operation thanks to the gearless, EC brushless motor and the unique airfoil design.
Ideal for integration with HVAC systems, to save energy saving and reduce CO2 emissions.
In the winter, they de-stratify the air, pushing the warm air towards the floor level and evening the temperature. This reduces the load on your HVAC system.
In the summertime, the constant and gentle breeze eliminates hot and cool spots in the building by improving the internal environment and creating a natural cooling effect. The air movement also helps keep insects away.
No ordinary maintenance.
Robust steel structure for long life.
Key safety features (main security wire, additional stabilising cables, hub safety ring).
Blade tips to optimise performance and acoustic comfort.
Hub cover to protect the motor from dust and bring better aesthetics.
Precabled for simplified electrical connection
Integrated EMC filters to prevent electromagnetic interference from other devices.

Specification

Steel upper motor protection frame.
Decorative canopy to cover the wiring
and the ceiling brackets.
Safety cables and an 800mm length
downrod are provided as standard.
Specially designed airfoil made from
aluminium EN AW 6063 T6. The
surface is anodized to avoid corrosion.
Aerodynamically shaped blade tips
formed in plastic.
Hub features an integral safety ring and aesthetic cover.
High-efficiency three-phase EC
brushless motor, specifically
designed for the HVLS application.
200-480Vac/3ph/50/60Hz, IP65,
with integrated electronic system and
EMC filters. Suitable for S1 continuous
service. Speed controllable.

Tested

Tested to the latest AMCA standard for
accurate, reliable information.
Designed and manufactured in
accordance with the Machinery Directive
(MD), Low Voltage Directive (LVD) and
Electromagnetic Compatibility Directive
(EMC).
